  • Silent Gensets - Air Cooled Series

25 kVA – Prime

Request A Quote Request A Quote
Download Catalogue Download Catalogue
1 Step 1
Get The Best Quote Now
reCaptcha v3
keyboard_arrow_leftPrevious
Nextkeyboard_arrow_right
FormCraft - WordPress form builder
1 Step 1
Download Brochure
reCaptcha v3
keyboard_arrow_leftPrevious
Nextkeyboard_arrow_right
FormCraft - WordPress form builder
Model No. TMTL-25-SP, TMTL-25-TP
Specification
Details
Genset Rating
25 kVA
Genset Model
TMTL-25-SP / TMTL-25-TP
Duty
Prime / Standby
Control Panel
Options Available for Manual and AMF
Acoustic Insulation Type
PU Fire Retardant
DG Set Dimensions (L × B × H)
2050 × 900 × 1275 mm
Fuel Tank Capacity
100 Liters
Dry Weight of DG Set
1050 kg (± 25 kg)
Engine Manufacturer
TAFE Motors and Tractors Limited
Engine Brand
Eicher Engines
Engine Model
329A-EG025
Number of Cylinders
3
Aspiration
Naturally Aspirated
Engine Power (Gross)
35.0 BHP
Reference Standard
Engine: ISO 3046-1, Genset: ISO 8528
Displacement
2945 cc
Compression Ratio
18.5 ± 0.5 : 1
Type of Governor
Electronic / Isochronous
Class of Governing
G3
Bore × Stroke
100 × 125 mm
Type of Cooling
Air Cooled
Lube Oil Sump Capacity (with Filters)
9.5 Liters
Coolant Capacity (Total)
N.A.
Coolant Capacity (Radiator)
N.A.
Battery
12 VDC, 88 / 90 Ah
Exhaust After Treatment System
DOC
Phase
1 / 3
Voltage
230 / 415 VAC
Power Alternator Type
Brushless with AVR, Single Bearing, Bell Housing: SAE 3/10
Power Factor
0.8 Lag
Rated Speed & Frequency
1500 RPM / 50 Hz
Engine Power (Gross)
25.5 kW
Fuel Injection System / FIP Type
Bosch CRS (CRS08)
Air Cleaner
Dry Type
Voltage Regulation
± 1%
Insulation
Class-H
Alternator Make
Stamford / Leroy Somer / CG / Meccalte
Starting System
Electric
Battery Make
Exide / TATA
Silencer Location & Type
Internal, Residential
Acoustic Insulation Thickness
40 mm on Body Panels (25 mm at Louvers)
Dry Weight (Engine)
437 kg
