Model No.
KN 12000 230V, 50Hz Connect
| Model No. | ATPT50 | ATPT70 | ATPT100 | ATPT125 | ATPT150 | ATPT150H | ATPT200 | ATPT250 |
|---|---|---|---|---|---|---|---|---|
| kVA | 5 | 7.5 | 10 | 12.5 | 15 | 15 | 20 | 25 |
| Type | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer |
| Body Type | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Winding | Copper | Copper | Copper | Copper | Copper | Copper | Copper | Copper |
| PF | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max Load AMP | 7 | 10.4 | 13.9 | 17.4 | 20.8 | 20.8 | 27.8 | 34.7 |
| RPM | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Eff % | 80 | 82.5 | 83.8 | 84 | 85 | 85 | 85 | 86 |
| Weight (Kg.) | 68 | 77 | 86 | 94 | 105 | 120 | 132 | 157 |
| Frame Size | 132 | 132 | 132 | 132 | 132 | 160 | 160 | 160 |
| Engine HP | 8 | 10 | 15 | 20 | 20 | 20 | 28 | 40 |
| Model No. | ATP300 | ATP350 | ATP400 | ATP500 | ATP630 | ATP750 | ATP825 | ATP100 |
|---|---|---|---|---|---|---|---|---|
| kVA | 30 | 35 | 40 | 50 | 63 | 75 | 82.5 | 100 |
| Type | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer | Transformer |
| Body Type | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Winding | Copper | Copper | Copper | Copper | Copper | Copper | Copper | Copper |
| PF | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max Load AMP | 41.7 | 48.6 | 55.6 | 69.5 | 87.6 | 104.3 | 114.7 | 136 |
| RPM | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Eff % | 87 | 88 | 88 | 88.1 | 89.2 | 90 | 90.03 | 90.3 |
| Weight (Kg.) | 175 | 180 | 182 | 223 | 251 | 322 | 331 | 340 |
| Frame Size | 160 | 160 | 200 | 200 | 200 | 200 | 200 | 200 |
| Engine HP | 45 | 45 | 50 | 60 | 80 | 100 | 100 | 125 |
